Specifications:

• Capacity pump 100 m3/h
• Machine cycle 15-40 sec.
• Dimensions 920 x 790 x 1125 mm
• Voltage 400V-3-50Hz(Other voltages available)
• Power 3.0 – 5.0 KW

DIMENSIONS

GENERAL

• Renowned series of stainless steel packaging machines for industrial applications
• Full range for vacuum and MAP packaging options
• Extensive program choices for specific packaging requirements
• Extremely large variety of applications in worldwide industrial productions
• User friendly and low maintenance, supplied with complete service program
• Well-balanced constructions and high quality materials guarantee durability

Food Products:

Industrial Production – Wholesale – Export Packaging (meat, poultry, fish, cheese, vegetables etc.)

• Longer shelf life / Optimal product and storage hygiene (no contamination, hermetically sealed)
• No loss of product (prevents drying out, moulds and freeze burn)
• Improved product quality (product maturing in packaging, no loss of aroma)
• Cost savings due to longer shelf life (larger purchasing amounts, re-packaging)
• Increased turnover due to longer shelf life (broader market, more variation in product range)
• Professional product presentation
• Optimal packaging contributes to food safety and HACCP standards

Non-Food Products:

Electronics – Semi-conductors – Metal – Pharmaceutical Products – Textiles – Laboratories etc.

• Moisture free anti-corrosive packaging
• Air and dust-free antistatic packaging
• Volume reducing packaging
• Product protecting and fraud resistant packaging

SPECIFICATIONS

• Single and double chamber floor models
• Stainless steel housing
• Stainless steel flat working plate
• Stainless steel lid
• Easily removable silicon holders for cleaning working plate
• Sealing mechanism mounted in lid
• Insert plates for adjusting vacuum chamber height

Packaging Functions

• Vacuum – Optimal final vacuum 99.99% (0,1 Mbar)
• Soft-air – Controlled ventilation for protection of product and packaging (optional)
• Gas-flush – Injecting food-gas for product protection and longer shelf life (optional)

Sealing Systems

• Double Seal – 2 x 3.5 mm convex sealing wire for optimal moisture elimination (double protection)
• Trennseal – 1 x 3.5 mm convex sealing wire + 1 x 1.1 mm round cutting wire / One time setting (cut off remaining flap) (optional)
• 1-2 Trennseal – 1 x 3.5 mm convex sealing wire + 1 x 1.1 mm round cutting wire / Independent time setting (shrink bags) (optional)
• Wide Seal – 1 x 8.0 mm flat sealing wire (optional)
• Bi-Active Seal – Upper and lower sealing bars with 1 x 5.0 mm flat sealing wire (thick and aluminium vacuum bags) (optional)

Operational Control Functions

• Digital Control – Time control / Automatic programming / 10 default programs
• Sensor Control – Set percentage pressure for vacuum and gas functions for accurate and constant packaging results / Automatic programming / 10 default programs / Vacuum plus time (optional)

Support Control Functions

• STOP button for partial/full cycle interruption
• Digital maintenance program for pump / Operating hours counter / Service indicator programs / Sleeper function etc.

Optional Functions / Accessories

• Service kit for standard maintenance
• Special control options for specific applications
• Special machine adaptations for specific products and/or production environments
